L.A.SLEEVE Sleeve - LA40 - [4" X 4-3/16" X 6"]
Information
Straight 3/32” wall repair sleeve. Outside diameter precision centerless ground to exact roundness for ease of installation.
- Manufacturer: L.A.SLEEVE
4” X 4-3/16” X 6”
Straight 3/32” wall repair sleeve.
Outside diameter precision centerless ground to exact roundness for ease of installation.
Inside diameter is semi-finished and must be bored and honed to size piston after installation.
Sleeve features chamfer on bottom inside and outside diameters.
Standard Bore Size 4.000”
Matched Vehicles
The following are a match for this product.
| American Motors 327 - 1969, 1968, 1967, 1966, 1965, 1964, 1963, 1962, 1961, 1960, 1959, 1958, 1957, 1956 |
| American Motors 151 2.5L - 1983, 1982, 1981, 1980 |
| Buick 350L 5.7L - 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985, 1984, 1983, 1982, 1981, 1980, 1979, 1978, 1977, 1976, 1975, 1974, 1973, 1972, 1971, 1970, 1969, 1968, 1967, 1966, 1965, 1964, 1963, 1962, 1961, 1960, 1959, 1958, 1957, 1956, 1955, 1954, 1953 |
| Buick 322 - 1956, 1955, 1954, 1953 |
| Buick 301 5.0L - 1981, 1980, 1979, 1978, 1977 |
| Buick 151 2.5L - 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985, 1984, 1983, 1982, 1981, 1980 |
| Cadillac 350 5.7L - 2000, 1999, 1998, 1997, 1996, 1995, 1994, 1993, 1992, 1991, 1990 |
| Chevrolet 350 5.7L - 1997, 1996, 1995, 1994, 1993, 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985, 1984, 1983, 1982, 1981, 1980, 1979, 1978, 1977, 1976, 1975, 1974, 1973, 1972, 1971, 1970, 1969, 1968, 1967, 1966, 1965, 1964, 1963, 1962 |
| Chevrolet 327 - 1974, 1973, 1972, 1971, 1970, 1969, 1968, 1967, 1966, 1965, 1964, 1963, 1962 |
| Chevrolet 302 - 1974, 1973, 1972, 1971, 1970, 1969, 1968, 1967, 1966, 1965, 1964, 1963, 1962 |
| Chevrolet 262 4.3L - 2005, 2004, 2003, 2002, 2001, 2000, 1999, 1998, 1997, 1996, 1995, 1994, 1993, 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985 |
| Chevrolet 151 2.5L - 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985, 1984, 1983, 1982, 1981, 1980, 1979, 1978 |
| GM 350 5.7L - 2000, 1999, 1998, 1997, 1996, 1995, 1994, 1993, 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985, 1984, 1983, 1982, 1981, 1980, 1979, 1978, 1977, 1976, 1975, 1974, 1973, 1972, 1971, 1970, 1969, 1968, 1967, 1966, 1965, 1964, 1963, 1962 |
| GM 350L 5.7L - 1997, 1996, 1995, 1994, 1993, 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985, 1984, 1983, 1982, 1981, 1980, 1979, 1978, 1977, 1976, 1975, 1974, 1973, 1972, 1971, 1970, 1969, 1968, 1967, 1966, 1965, 1964, 1963, 1962, 1961, 1960, 1959, 1958, 1957, 1956, 1955, 1954, 1953 |
| GM 327 - 1974, 1973, 1972, 1971, 1970, 1969, 1968, 1967, 1966, 1965, 1964, 1963, 1962 |
| GM 302 - 1974, 1973, 1972, 1971, 1970, 1969, 1968, 1967, 1966, 1965, 1964, 1963, 1962 |
| GM 301 5.0L - 1981, 1980, 1979, 1978, 1977 |
| GM 262 4.3L - 2005, 2004, 2003, 2002, 2001, 2000, 1999, 1998, 1997, 1996, 1995, 1994, 1993, 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985 |
| GM 151 2.5L - 1993, 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985, 1984, 1983, 1982, 1981, 1980, 1979, 1978, 1977 |
| Lincoln 351 5.8L - 1974, 1973, 1972, 1971, 1970 |
| Mercury 351 5.8L - 1975, 1974, 1973, 1972, 1971, 1970 |
| Oldsmobile 350L 5.7L - 1991, 1990, 1989, 1988, 1987, 1986, 1985, 1984, 1983, 1982, 1981, 1980, 1979, 1978, 1977 |
| Oldsmobile 301 5.0L - 1981, 1980, 1979, 1978, 1977 |
| Oldsmobile 151 2.5L - 1995, 1994, 1993, 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985, 1984, 1983, 1982, 1981, 1980, 1979, 1978, 1977 |
| Pontiac 350L 5.7L - 1997, 1996, 1995, 1994, 1993, 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985, 1984, 1983, 1982, 1981, 1980, 1979, 1978, 1977 |
| Pontiac 301 5.0L - 1981, 1980, 1979, 1978, 1977 |
| Pontiac 262 4.3L - 2005, 2004, 2003, 2002, 2001, 2000, 1999, 1998, 1997, 1996, 1995, 1994, 1993, 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985 |
| Pontiac 151 2.5L - 1993, 1992, 1991, 1990, 1989, 1988, 1987, 1986, 1985, 1984, 1983, 1982, 1981, 1980, 1979, 1978, 1977 |
L.A.SLEEVE
L.A. Sleeve Co manufactures centrifugally spun-cast high performance cylinder sleeves and liners for all industries. Automotive, Heavy Duty, Industrial, Motorcycle, ATV, PWC, Snowmobile, Marine, Scooter, and High Performance racing to name a few. We are also not limited to these industries, we provide cylinder liners for original equipment manufacturing to single custom designed sleeves. We also offer various aftermarket solutions and products to expanding markets to give you the best advantage. L.A. Sleeve provides high quality and high performance Cylinder Kits, big bore or standard bore kits to give you the needed advantage along with carburator kits, MX/ATV EFI tuning, custom designed sleeves, motor installation to name a few of our product development and services provided.
